JT-2A 2013 new Shanghai sliding model c arm compatible operating table

FOB Reference Price:Get Latest Price
US $1,000-50,000 / Set | 1 Set/Sets min:max (Min. Order)
Supply Ability:
5000 Set/Sets per Month OEM
Port:
shanghai
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Shanghai, China (Mainland)
Brand Name:
Poweflower
Model Number:
JT-2A
Properties:
Abdominal Surgery Equipments
Type:
operation table
Name:
c arm compatible operating table
Specific use:
in hospital
Warranty time:
1 year
Certificate 1:
multi-function table approved by CE
Certificate 2:
ISO9001
Certificate 3:
ISO13485
OEM or customize:
available
Payment Terms:
30%TT in advance 70% before shipment
Packaging & Delivery
Packaging Details
Wooden case and plastic packaging inside
Delivery Time
within 15 working days after payment

Specifications

c arm compatible operating table
1:CE&ISO Certificate
2:Economic design & OEM
3:Discounted price

JT-2A high quality sliding model hydraulic c arm compatible operating table



multi-function table
1:CE&ISO Certificate
2:Ergonomic design & OEM
3:Discounted price
4:Service:lifetime





Description

This table is professional used for medical image.

And also this table is a multi-function purpose table ,which is also used for operations and examination of thoracic surgery, abdominal surgery, orthopaedics,cerebral surgery, ophthalmology,otorhinolaryngology,obstetrics and gynecology and urinary surgery.

There is a shelf fixed under the table ,Cassette can be put on the shelf and adjusted to the radiography position,then X-ray radiography is taken. The mattress is made of foam polyurethane. The bottom seat is movable and can be locked. Using the imported air-spring ,the table has got the best position for the clinical uses with its unique hydropneumatic technology and is convenient to operate, so it is helpful to improve operation efficiency of doctors.

The translational function operated by manual and translation distance is more than 300mm.

Technical data

Size of table

1960mm*480mm

Max height of the table top

930mm

Min height of the table top

690mm

Reversed trendelenburg

25 °

Trendelenburg

20°

Lateral tilt

18°

Leg panel adjustment

 90°

Back panel adjustment

up75°   down10°

Head panel adjustment

up45°   down50°

Rated load weight of mesa

200 kg
